CDH1 MT4 Mill Type Cylinder

Get Latest Price

Contact Now

Product Description

Product Attributes

Model No.: CDH1 MT4 125 70-200

Brand: Guoyue

Origin: China

Warranty Period: 1.5 Years

Out-of-warranty Service: Video Technical Support, Online Support

Place Of Origin: China

Service System: Online Support, Video Technical Support

Maximum Stroke: 200mm

Inner Tube Diameter: 125mm

Support Customization: Oem, Odm

Packaging & Delivery

The file is encrypted. Please fill in the following information to continue accessing it

CDH1 MT4 125 70-200 Hydraulic Cylinder



Product Description

CDH1 MT4 Mill Type Cylinder

Manufactured in strict accordance with ISO 6022 and DIN 24333 international standards to ensure maximum reliability in heavy-duty environments.
Standard bore diameter of 125mm paired with a 70mm high-strength piston rod, delivering high force density for short-stroke industrial cycles.
Features the MT4 intermediate trunnion mounting design, specifically engineered to manage oscillating loads and non-linear load paths.
Nominal working pressure of 250 Bar (25 MPa), with every unit undergoing a 1.5x static pressure proof test to verify structural integrity.
Piston rods are induction hardened and precision ground with a hard chrome plating thickness of 30-50μm to prevent wear and corrosion.
Equipped with premium, high-temperature resistant sealing systems (Parker/SKF) to ensure zero-leakage performance in harsh metallurgical conditions.
Provides 100% mechanical and dimensional interchangeability with the Rexroth CDH1 series, simplifying direct replacement and maintenance.
Optimized for high-cycle applications such as steel mill ladle control, heavy-duty forging presses, and specialized infrastructure machinery.
