CDL1 MT4 Tie Rod Cylinder

Name: CDL1 MT4 80 50-100 Hydraulic Cylinder
Uploaded: 2026-05-14T14:20:34+08:00
Description: CD Series, CG Series, Differential Cylinder, Double Acting Cylinder,Tie Rod Hydraulic Cylinder Product Usage:

Get Latest Price

Payment Type:	L/C,T/T,Paypal
Incoterm:	FOB,CIF,EXW
Min. Order:	1
Transportation:	Ocean,Land,Air

Contact Now

Product Description

Product Attributes

Model No.: CDL1 MT4 80/50-100

Brand: Guoyue

Origin: China

Warranty Period: 1.5 Years

Out-of-warranty Service: Video Technical Support

Where To Provide Local Services (in Which Countries Are There Overseas Service Outlets): None

Showroom Location (in Which Countries Are There Sample Rooms Overseas): None

Place Of Origin: China

Service System: Online Support, Video Technical Support

Maximum Stroke: 100mm

Inner Tube Diameter: 80mm

Support Customization: Oem, Odm

Packaging & Delivery

Package Type

Wooden Package

The file is encrypted. Please fill in the following information to continue accessing it

CDL1 MT4 80 50-100 Hydraulic Cylinder



Product Description

CD Series, CG Series, Differential Cylinder, Double Acting Cylinder,Tie Rod Hydraulic Cylinder

Product Usage: Mainly used for linear reciprocating motion in automation equipment for medium and light industries. With its standard pull rod structure, it is particularly suitable for working conditions that require frequent maintenance, replacement of seals, or have certain requirements for space weight.

Core specifications:

Model: CDL1 MT4 series (compliant with ISO 6020/1 standard)

Size: Cylinder diameter 80mm/Rod diameter 50mm/Stroke 100mm

Installation method: Middle ear shaft installation (MT4), supports multi angle swing.

Working pressure: rated pressure of 16MPa (160bar), up to a maximum of 21MPa.

Technical advantages:

High precision guidance: Using an elongated guide sleeve, it can maintain extremely high straightness even within a 100mm stroke, reducing wear caused by unbalanced loads.

Differential Design: Utilizing the area difference between the two ends of the piston to achieve rapid extension action, significantly improving production cycle efficiency.

Differentiation advantage:

Compared with similar products, the CDL1 series of Guoyue Hydraulic has undergone strengthening treatment on the rod material, with higher tensile strength than ordinary 45 # steel, and is less prone to fatigue cracks under long-term high-frequency reciprocating.

Strong interchangeability: Fully compatible with international brand standards such as Rexroth, customers can directly replace without modifying the installation position, significantly reducing maintenance costs.

Structural principle: The front and rear end caps are fastened to the cylinder barrel as a whole through four high-strength tie rods. This "building block" design not only reduces the overall weight, but also makes the oil cylinder more evenly stressed when under pressure.

Sealing principle: Adopting an imported multi combination sealing system (such as step seal+slip ring combination), it achieves "zero leakage" while significantly reducing frictional resistance and starting pressure.

Usage scenario

Injection molding and mold machinery: used for the opening and closing or ejection actions of molds, MT4 ear shaft installation can adapt to small arc deviations in mold movements.

Packaging and Light Industry Machinery: Utilizing its differential fast response characteristics for rapid pushing, pulling, and conveying of materials.

Woodworking and aluminum equipment: Provides stable hydraulic power in processes such as compression, cutting, and feeding.
